Combination Horizontal Alignment/Intersection, Black and White

| View Cart ⇗ | Info

“The horizontal alignment Turn signs may be used in advance of situations where the horizontal roadway alignment changes. The Turn sign or the Curve sign may be combined with the Cross Road sign or the Side Road sign to create a combination Horizontal Alignment/Intersection sign that depicts the condition where an intersection occurs within a turn or curve.”

Source

Federal Highway Administration Manual on Uniform Traffic Control Devices for Streets and Highways, 2003 Edition (including 2004 and 2007 revisions) (Washington, DC: United States Department of Transportation, 2007)

Downloads

EPS (vector)

388.3 KiB

TIFF (full resolution)

3000×3000, 347.1 KiB

Large GIF

1024×1024, 26.9 KiB

Medium GIF

640×640, 18.0 KiB

Small GIF

320×320, 7.0 KiB
