Entering Roadway Merge, Color
| View Cart ⇗ | Info
When a Merge sign is to be installed on an entering roadway that curves before merging with the major roadway, such as a ramp with a curving horizontal alignment as it approaches the major roadway, the Entering Roadway Merge sign should be used to better portray the actual geometric conditions to road users on the entering roadway.
Galleries
Advisory and Warning SignsSource
Federal Highway Administration Manual on Uniform Traffic Control Devices for Streets and Highways, 2003 Edition (including 2004 and 2007 revisions) (Washington, DC: United States Department of Transportation, 2007)
