Triple Reverse Curve, Outline

| View Cart ⇗ | Info

The horizontal alignment Reverse Curve signs may be used in advance of situations where the horizontal roadway alignment changes. This sign indicates that three lanes in the road ahead curve to the right and then immediately curve back to the left.

Source

Federal Highway Administration Manual on Uniform Traffic Control Devices for Streets and Highways, 2003 Edition (including 2004 and 2007 revisions) (Washington, DC: United States Department of Transportation, 2007)
