Triple Reverse Curve, Outline

| View Cart ⇗ | Info

The Double Reverse Curve sign may be used when the tangent distance between two reverse curves is less than 180 m (600 ft), thus making it difficult for a second Reverse Curve sign to be placed between the curves.

Source

Federal Highway Administration Manual on Uniform Traffic Control Devices for Streets and Highways, 2003 Edition (including 2004 and 2007 revisions) (Washington, DC: United States Department of Transportation, 2007)
