School Advance Warning, Outline
To use any of the clipart images above (including the thumbnail image in the top left corner), just click and drag the picture to your desktop. You may also control-click (Mac) or right-click (Windows) and choose "Save file to disk" from the pop-up menu. Click here for help downloading and using clipart files.
* A TIFF file is a high-resolution (240 dpi) format. TIFF files should be used only if you are printing the clipart. Do NOT use TIFF files for clipart that will displayed on a computer screen. Click here for help downloading and using TIFF files.* This clipart is also available as an Encapsulated Postscript file. EPS files are scalable and may be used in vector graphics applications such as Freehand or Illustrator and in word processors such as AppleWorks or Word. Click here for help downloading and using EPS files. File Name: 68258_642_S1-1_o
Description: The School Advance Warning assembly should be installed in advance of locations where school buildings or grounds are adjacent to the highway, except where a physical barrier such as fencing separates school children from the highway. The School Advance Warning assembly shall be used in advance of any installation of the School Crosswalk Warning assembly, or in advance of the first installation of the School Speed Limit assembly. If used, the School Advance Warning assembly shall be installed not less than 45 m (150 ft) nor more than 210 m (700 ft) in advance of the school grounds or school crossings. If used, the School Advance Warning assembly shall consist of a School Advance Warning sign supplemented with a plaque with the legend AHEAD or XXX METERS (XXX FEET) to provide advance notice to road users of crossing activity.
Source: Federal Highway Administration Manual on Uniform Traffic Control Devices for Streets and Highways, 2003 Edition (including 2004 and 2007 revisions) (Washington: United States Department of Transportation, 2007) 642
Keywords: kadvisoutline, school zone sign, school sign, school ahead
Copyright: 2009, Florida Center for Instructional Technology. See license.
