Lane Ends, Outline

| View Cart ⇗ | Info

The Lane Ends symbol sign, should be used to warn of the reduction in the number of traffic lanes in the direction of travel on a multi-lane highway.

Source

Federal Highway Administration Manual on Uniform Traffic Control Devices for Streets and Highways, 2003 Edition (including 2004 and 2007 revisions) (Washington, DC: United States Department of Transportation, 2007)

Downloads

EPS (vector)

387.4 KiB

TIFF (full resolution)

3000×3000, 382.4 KiB

Large GIF

1024×1024, 29.7 KiB

Medium GIF

640×640, 19.2 KiB

Small GIF

320×320, 6.7 KiB
