Entering Roadway Added Lane, Black and White

| View Cart ⇗ | Info

When an Added Lane sign is to be installed on a roadway that curves before converging with another roadway that has a tangent alignment at the point of convergence, the Entering Roadway Added Lane sign should be used to better portray the actual geometric conditions to road users on the curving roadway.


Federal Highway Administration Manual on Uniform Traffic Control Devices for Streets and Highways, 2003 Edition (including 2004 and 2007 revisions) (Washington, DC: United States Department of Transportation, 2007)
